Tip122 Transistor

Name: Tip122 Transistor
Brand: ELECTROLOGICS DEVICES
Price: 10 INR
Availability: InStock

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 1000 Pieces

Tip122 Transistor Specification

Input
Base Current

Power Supply
Not Applicable (Passive Component)

Response Time
Fast Switching

Output
Collector Current

Interface
Through Hole

Power Source
Externally Powered in Circuit

Features
High Gain, Fast Switching, Darlington Pair

Thermal Conductivity
1.25 W/C (Junction to Case)

Components
Silicon NPN Darlington Power Transistor

IP Rating
Not Rated

Operating Temperature
-65C to +150C

Usage
Switching and Amplifier Applications

Product Type
Transistor

Application
General Purpose Switching, Audio Amplifier, Voltage Regulation

Rated Voltage
100 V (Collector-Emitter Voltage)

Supply Voltage
100 V Max

Size
TO-220 Package

Dimension (L*W*H)
15.5 mm x 10.3 mm x 4.5 mm (Body)

Function
NPN Power Transistor

Color
Black (Body), Silver (Leads)

Weight
Approx. 2.1 g

Current Rating
8A Continuous

Thickness
Approx. 4.5 mm (Body)

Capacity
8A Collector Current

Frequency
3 MHz (Transition Frequency)

Pin Count
3 Pins

Collector-Emitter Saturation Voltage
2 V max @ 8A

Lead Material
Tin Plated Copper

Emitter Base Voltage (VEBO)
5 V

DC Current Gain (hFE)
1000 (Min)

Package Type
TO-220

Mounting Type
Through Hole

Collector Base Voltage (VCBO)
100 V

Tip122 Transistor Trade Information

Minimum Order Quantity
1000 Pieces

Payment Terms
Cash on Delivery (COD), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Delivery Point (DP), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
10000 Pieces Per Day

Delivery Time
5 Days

About Tip122 Transistor

Discover the venerable TIP122 Transistor, celebrated for its meritorious performance and valuable role in general-purpose switching and amplifier circuits. Take advantage of our best price and experience remarkable savings on this high-gain, fast-switching Silicon NPN Darlington Power Transistor. With a robust collector-emitter voltage of 100 V and continuous current rating of 8A, this powerhouse features a durable TO-220 black body with silver leads. Suitable for audio amplifiers, voltage regulation, and more, it is essential for distributors, exporters, suppliers, and traders in India.

Applications and Usage

The TIP122 transistor is widely used for general-purpose switching, audio amplifier circuits, and voltage regulation. It is usually employed as an NPN power transistor in various application media, ranging from industrial control equipment to consumer electronics. Used as a vital component in circuit boards, it ensures efficient performance in switching and amplifier tasks thanks to its high current gain and fast switching capabilities.

Payment and Sample Solutions

Tip122 Transistor purchases are subject to standard payment terms, with charges varying by order volume and specification. Sample policies are designed to minimize expenditure, with freight costs typically borne by the buyer. For convenience, samples of the TIP122 Transistor are available to validate quality and compatibility before bulk orders, ensuring transparency and satisfaction for both local and international clients.

FAQ's of Tip122 Transistor:

Q: How is the TIP122 transistor used in switching and amplifier applications?

A: The TIP122 transistor serves as a switch or signal amplifier in electronic circuits, leveraging its high DC current gain and fast response time for reliable performance in switching loads and amplifying audio signals.

Q: What benefits does the Darlington configuration of the TIP122 offer?

A: The Darlington pair structure of the TIP122 provides exceptional current gain, enabling improved efficiency and higher output levels, which is especially valuable in audio amplification and voltage regulation tasks.

Q: Where can the TIP122 transistor be sourced and shipped from in India?

A: TIP122 transistors are available from trusted distributors, exporters, suppliers, and traders across India, who can arrange domestic or international shipment as required.

Q: What is the process for obtaining TIP122 transistor samples?

A: Interested buyers can request TIP122 samples from suppliers. Usually, the buyer covers the shipping (freight) charges, and the sample policy aims to minimize additional expenditure before large-scale purchases.

Q: When should the TIP122 transistor be used over a standard NPN transistor?

A: The TIP122 is preferred when high current gain, fast switching speed, and robust collector-emitter voltage are required, making it advantageous for audio amplifiers, general switching, or voltage regulation projects.
