Tip122 Transistor

Price: 10 INR

Piece

Minimum Order Quantity : 1000 Piece

Application:General Purpose Switching, Audio Amplifier, Voltage Regulation

Capacity:8A Collector Current

Color:Black (Body), Silver (Leads)

Components:Silicon NPN Darlington Power Transistor

Current Rating:8A Continuous

Dimension (L*W*H):15.5 mm x 10.3 mm x 4.5 mm (Body)

Features:High Gain, Fast Switching, Darlington Pair

Frequency:3 MHz (Transition Frequency)

Function:NPN Power Transistor

IP Rating:Not Rated

Input:Base Current

Interface:Through Hole

Operating Temperature:-65Â°C to +150Â°C

Output:Collector Current

Power Source:Externally Powered in Circuit

Power Supply:Not Applicable (Passive Component)

Product Type:Transistor

Rated Voltage:100 V (Collector-Emitter Voltage)

Response Time:Fast Switching

Size:TO-220 Package

Supply Voltage:100 V Max

Thermal Conductivity:1.25 W/Â°C (Junction to Case)

Thickness:Approx. 4.5 mm (Body)

Usage:Switching and Amplifier Applications

Weight:Approx. 2.1 g

Know More

Discover the venerable TIP122 Transistor, celebrated for its meritorious performance and valuable role in general-purpose switching and amplifier circuits. Take advantage of our best price and experience remarkable savings on this high-gain, fast-switching Silicon NPN Darlington Power Transistor. With a robust collector-emitter voltage of 100 V and continuous current rating of 8A, this powerhouse features a durable TO-220 black body with silver leads. Suitable for audio amplifiers, voltage regulation, and more, it is essential for distributors, exporters, suppliers, and traders in India.

Applications and Usage

The TIP122 transistor is widely used for general-purpose switching, audio amplifier circuits, and voltage regulation. It is usually employed as an NPN power transistor in various application media, ranging from industrial control equipment to consumer electronics. Used as a vital component in circuit boards, it ensures efficient performance in switching and amplifier tasks thanks to its high current gain and fast switching capabilities.

Payment and Sample Solutions

Tip122 Transistor purchases are subject to standard payment terms, with charges varying by order volume and specification. Sample policies are designed to minimize expenditure, with freight costs typically borne by the buyer. For convenience, samples of the TIP122 Transistor are available to validate quality and compatibility before bulk orders, ensuring transparency and satisfaction for both local and international clients.

FAQ's of Tip122 Transistor:

Q: How is the TIP122 transistor used in switching and amplifier applications?

A: The TIP122 transistor serves as a switch or signal amplifier in electronic circuits, leveraging its high DC current gain and fast response time for reliable performance in switching loads and amplifying audio signals.

Q: What benefits does the Darlington configuration of the TIP122 offer?

A: The Darlington pair structure of the TIP122 provides exceptional current gain, enabling improved efficiency and higher output levels, which is especially valuable in audio amplification and voltage regulation tasks.

Q: Where can the TIP122 transistor be sourced and shipped from in India?

A: TIP122 transistors are available from trusted distributors, exporters, suppliers, and traders across India, who can arrange domestic or international shipment as required.

Q: What is the process for obtaining TIP122 transistor samples?

A: Interested buyers can request TIP122 samples from suppliers. Usually, the buyer covers the shipping (freight) charges, and the sample policy aims to minimize additional expenditure before large-scale purchases.

Q: When should the TIP122 transistor be used over a standard NPN transistor?

A: The TIP122 is preferred when high current gain, fast switching speed, and robust collector-emitter voltage are required, making it advantageous for audio amplifiers, general switching, or voltage regulation projects.
